The YEJ series motor is a derivative product composed of a disc DC electromagnet brake attached between the fan and end cover of the Y2 series motor . It has high efficiency and energy saving, large starting torque, rapid braking, accurate positioning, simple structure, easy operation,low vibration, long-term lifespan ,no axial movement of the rotor during braking, etc. .It is widely used in various machineries requiring rapid stopping, accurate positioning, and reciprocating motion, such as lifting, food processing, light industry packaging, printing, Construction and other machinery.
Conditions of use
Ambient temperature: changes with seasons, but does not exceed-15℃~40℃
Altitude: no more than 1000m
Rated frequency: 50Hz
Rated voltage: 380V
Connection method: Y connection of 3kW and below, △ connection of 4 kW and above.
Working method: Continuous (S1)
Protection level: IP44, brake: IP23
Cooling method: IC141
Insulation level: Class B
Brake method: Non-excitation braking. The braking power supply is provided by the rectifier inside of the motor junction box. For H100 frames and below, it is AC220V-DC99V; for H112 frames and above, it is AC380V-DC170V.
